Key Features
Technical Specifications
Chamber Temperature
0°C to -35°C ±5 K, adjustable in 1 K increments (at 20°C ambient)
Specimen Head
Down to -50°C
Peltier Station
Down to -60°C
Display
12-inch colour intuitive touchscreen
Defrosting
Automatic and manual, custom scheduling up to 24 hr cycle
Freezing Stations
20 stations + 3 Peltier elements
Maximum Specimen Size
50 x 80 mm
Specimen Orientation
8° (orientation section)
Coarse Feed
300 µm/s (slow) / 900 µm/s
Section Thickness
1-100 µm in fine increments
Trimming Thickness
5-600 µm in fine increments
Horizontal Feed
28 ± 1 mm
Vertical Stroke
59 ± 1 mm
Safety
UVC disinfection 30 or 180 min, hand-wheel lock, finger protection
Dimensions
~830 x 820 x 1225 mm (hand-wheel included)
Power Supply
220 V / 50 Hz
Enquire about this product
Get pricing, technical specs, or schedule a call with our applications team.
Request Quote Contact on WhatsAppApplications
Frozen sections
Intra-operative diagnosis
Clinical pathology
Research cryosectioning
Certifications
ISO 13485CDSCOIEC
